Technical parameter
|
Manufacturer model |
International Mode |
Specifications(mm) |
Concentrated loa |
limit load |
Uniformly distributed load (N/m2) |
Fireproof performanc |
||
|
LB |
N |
KG |
||||||
|
ZL-501 |
HDG(CQ) |
500x500x28 |
600 |
1960 |
200 |
≥5880 |
≥9720 |
A |
|
ZL-502 |
HDG(Q) |
500x500x28 |
700 |
2950 |
300 |
≥8850 |
≥12500 |
A |
|
ZL-503 |
HDG(B) |
500x500x28 |
900 |
4450 |
450 |
≥13350 |
≥23000 |
A |
|
ZL-504 |
HDG(Z) |
500x500x28 |
1150 |
5560 |
567 |
≥16680 |
≥33000 |
A |
